We choose Carbon,Aramid, S glass fiber as raw materials and use Woven and knitting machine to produce woven fabric and Multiaxial fabric. It is ideal for applications such as wind blades, marine panel, sport &leisure products, truck and trailer panels….
| Produce No | Glass | Weight(g/m2) | Density (end/cm) | Input Yarn | Weave |
| Warp | Weft | Warp | Weft |
CWP200 | Carbon | 200 | 5 | 5 | 3K | 3K | Plain |
CWT200 | Carbon | 200 | 5 | 5 | 3K | 3K | Twill |
CWT245 | Carbon | 245 | 6.1 | 6.1 | 3K | 3K | Twill |
CWUD200 | Carbon | 199 | 2.4 | 1.9 | 12K | Glass Yarn | Plain/UD |
CWUD300 | Carbon | 296 | 3.6 | 1.9 | 12K | Glass Yarn | Plain/UD |
CWP400 | Carbon | 400 | 2.5 | 2.5 | 12K | 12K | Plain |
AWP170 | Aramid | 170 | 5 | 5 | 1500D | 1500D | Plain |
CAWT165 | Carbon/Aramid | 165 | 5 | 6 | 3K/1000D | 3K/1000D | Twill |
Typical Type:
Product No. | Overall Density（g/m2） | +0°Roving Density（g/m2） | +45°Roving Density（g/m2） | 90°Roving Density（g/m2） | -45°Roving Density（g/m2） | ChopDensity （g/m2）
| Polyester Yarn Density（g/m2） | Material |
CKUDL150 | 170 | 154 | / | 10 | / | / | 6 | Carbon 12K |
CKUDL300 | 319 | 303 | / | 10 | / | / | 6 | Carbon 12K |
CKBX300 | 306 | / | 150 | / | 150 | / | 6 | Carbon 12K |
CKBX400 | 406 | / | 200 | / | 200 | / | 6 | Carbon 12K |
CKBX600 | 606 | / | 300 | / | 300 | / | 6 | Carbon 24K |
CKLT300 | 306 | 150 | / | 150 | / | / | 6 | Carbon 12K |
| CKLT400 | 406 | 200 | / | 200 | / | / | 6 | Carbon 12K |
CKLT600 | 606 | 300 | / | 300 | / | / | 6 | Carbon 24K |
CKQX800 | 806 | 200 | 200 | 200 | 200 | / | 6 | Carbon 12K |
EAKBXM625 | 635 | / | 100/100 | / | 100/100 | 225 | 10 | Aramid/Glass |
ECKLTM825 | 837 | 150/150 | / | 150/150 | N/A | 225 | 12 | 12K/Glass |
The above information is for reference only, in view of product variety and application conditions diversity, all of above information should be as specific user properly adjust the situation.
